170335-3107
  • Share:

Molex 170335-3107

Manufacturer No:
170335-3107
Manufacturer:
Molex
Package:
Box
Datasheet:
170335-3107 Datasheet
ECAD Model:
-
Description:
IMPACT 85-OHM BP 4X10 GL SN
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Connector Usage:-
Connector Type:Header, Male Pins
Connector Style:Impact, Guide Left
Number of Positions:120
Number of Positions Loaded:All
Pitch:-
Number of Rows:12
Number of Columns:10
Mounting Type:Through Hole
Termination:Press-Fit
Contact Layout, Typical:40 Differential Pairs
Features:-
Contact Finish:Gold
Contact Finish Thickness:30.0µin (0.76µm)
Color:Gray
0 Remaining View Similar

In Stock

$15.19
23

Please send RFQ , we will respond immediately.

Similar Products

Part Number 170335-3107 170335-3807   170335-5107   170335-3607   170335-3106
Manufacturer Molex Molex Molex Molex Molex
Product Status Active Active Active Active Active
Connector Usage - - - - -
Connector Type Header, Male Pins Header, Male Pins Header, Male Pins Header, Male Pins Header, Male Pins
Connector Style Impact, Guide Left Impact, Guide Left Impact, Guide Right Impact, Guide Left Impact, Guide Left
Number of Positions 120 96 120 192 120
Number of Positions Loaded All All All All All
Pitch - - - - -
Number of Rows 12 12 12 12 12
Number of Columns 10 8 10 16 10
Mounting Type Through Hole Through Hole Through Hole Through Hole Through Hole
Termination Press-Fit Press-Fit Press-Fit Press-Fit Press-Fit
Contact Layout, Typical 40 Differential Pairs 32 Differential Pairs 40 Differential Pairs 64 Differential Pairs 40 Differential Pairs
Features - - - - -
Contact Finish Gold Gold Gold Gold Gold
Contact Finish Thickness 30.0µin (0.76µm) 30.0µin (0.76µm) 30.0µin (0.76µm) 30.0µin (0.76µm) 30.0µin (0.76µm)
Color Gray Gray Gray Gray Gray
