Molex 09-65-2029

Manufacturer No:
09-65-2029
Manufacturer:
Molex
Package:
Bag
Datasheet:
09-65-2029 Datasheet
ECAD Model:
-
Description:
2CKT 3.96MM WFAS W/LOCK 52
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Connector Type:Header
Contact Type:Male Pin
Pitch - Mating:0.156" (3.96mm)
Number of Positions:2
Number of Rows:1
Row Spacing - Mating:-
Number of Positions Loaded:All
Style:Board to Cable/Wire
Shrouding:Shrouded - 1 Wall
Mounting Type:Through Hole
Termination:Solder
Fastening Type:Friction Lock
Contact Length - Mating:0.419" (10.65mm)
Contact Length - Post:0.142" (3.60mm)
Overall Contact Length:0.687" (17.45mm)
Insulation Height:0.482" (12.25mm)
Contact Shape:Square
Contact Finish - Mating:Tin
Contact Finish Thickness - Mating:-
Contact Finish - Post:Tin
Contact Material:Brass
Insulation Material:Polyamide (PA66), Nylon 6/6
Features:-
Operating Temperature:-
Ingress Protection:-
Material Flammability Rating:UL94 V-2
Insulation Color:-
Current Rating (Amps):-
Voltage Rating:-
