Molex 0395345008

Manufacturer No:
0395345008
Manufacturer:
Molex
Package:
Bulk
Datasheet:
0395345008 Datasheet
ECAD Model:
-
Description:
TERM BLOCK PLUG 8POS STR 5.08MM
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Type:Plug, Female Sockets
Number of Positions:8
Positions Per Level:8
Number of Levels:1
Pitch:0.200" (5.08mm)
Header Orientation:-
Plug Wire Entry:180°
Termination Style:Screw - Rising Cage Clamp
Mounting Type:Free Hanging (In-Line)
Current - IEC:-
Voltage - IEC:-
Current - UL:18 A
Voltage - UL:300 V
Wire Gauge or Range - AWG:12-30 AWG
Wire Gauge or Range - mm²:-
Color:Green
Operating Temperature:-40°C ~ 115°C
Contact Mating Finish:Tin
Features:Mating Flange
0 Remaining View Similar

In Stock

$7.04
94

Please send RFQ , we will respond immediately.
