Molex 0010845151

Manufacturer No:
0010845151
Manufacturer:
Molex
Package:
Bulk
Datasheet:
0010845151 Datasheet
ECAD Model:
-
Description:
CONN HDR 15POS 0.25 TIN PCB
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Connector Type:Header
Contact Type:Female Socket
Style:Board to Cable/Wire
Number of Positions:15
Number of Positions Loaded:All
Pitch - Mating:0.250" (6.35mm)
Number of Rows:3
Row Spacing - Mating:0.250" (6.35mm)
Mounting Type:Through Hole
Termination:Solder
Fastening Type:Locking Ramp
Contact Finish - Mating:Tin
Contact Finish Thickness - Mating:137.8µin (3.50µm)
Insulation Color:Natural
Insulation Height:0.550" (13.97mm)
Contact Length - Post:0.169" (4.30mm)
Operating Temperature:-55°C ~ 105°C
Material Flammability Rating:UL94 V-0
Contact Finish - Post:Tin
Mated Stacking Heights:-
Ingress Protection:-
Features:-
Current Rating (Amps):-
Voltage Rating:600V
0 Remaining View Similar

In Stock

$1.57
48

Please send RFQ , we will respond immediately.
