| Part Number | GVA-63+ | GVA-93+ | GVA-83+ | GVA-60+ | GVA-62+ |
|---|---|---|---|---|---|
| Manufacturer | Mini-Circuits | Mini-Circuits | Mini-Circuits | Mini-Circuits | Mini-Circuits |
| Product Status | Active | Active | Active | Active | Active |
| Frequency | 10MHz ~ 6GHz | 10MHz ~ 9GHz | 0Hz ~ 7GHz | 10MHz ~ 5GHz | 10MHz ~ 6GHz |
| P1dB | 15.9dBm | 16.3dBm | 18.6dBm | 20.1dBm | 19.8dBm |
| Gain | 15.9dB | 15.2dB | 11.2dB | 14.2dB | 14.5dB |
| Noise Figure | 4.6dB | 5.3dB | 7.5dB | 4.5dB | 5.6dB |
| RF Type | CATV, DBS, LTE, MMDS, Wireless LAN | LTE, MMDS, Wireless LAN | CATV, DBS, LTE, MMDS, Wireless LAN | CATV, DBS, LTE, MMDS, Wireless LAN | CATV, DBS, LTE, MMDS, Wireless LAN |
| Voltage - Supply | 4.8V ~ 5.2V | 4.8V ~ 5.2V | 4.8V ~ 5.2V | 4.8V ~ 5.2V | 4.8V ~ 5.2V |
| Current - Supply | 69mA | 52mA | 72mA | 92mA | 82mA |
| Test Frequency | 800MHz | 850MHz | 2GHz | 50MHz | 800MHz |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | TO-243AA | TO-243AA | TO-243AA | TO-243AA | TO-243AA |
| Supplier Device Package | SOT-89 | SOT-89 | SOT-89 | SOT-89 | SOT-89 |
