| Part Number | GP2X+ | GP2X1+ | GP2Y+ | GP2S+ |
|---|---|---|---|---|
| Manufacturer | Mini-Circuits | Mini-Circuits | Mini-Circuits | Mini-Circuits |
| Product Status | Active | Active | Active | Active |
| Insertion Loss | 0.6dB | 0.8dB | 0.8dB | 0.8dB |
| Frequency | 2.9 GHz ~ 6.2 GHz | 2.8 GHz ~ 7.2 GHz | 1.6 GHz ~ 3.3 GHz | 800 MHz ~ 2.1 GHz |
| Specifications | Isolation (Min) 15dB, 1.2 VSWR (Typ), 9° Imbalance (Max) | Isolation (Min) 10dB, 1.3 VSWR (Typ), 10° Imbalance (Max) | Isolation (Min) 17dB, 1.2 VSWR (Typ), 4° Imbalance (Max) | Isolation (Min) 17dB, 1.2 VSWR (Typ), 4° Imbalance (Max) |
| Size / Dimension | 0.118" L x 0.118" W x 0.039" H (3.00mm x 3.00mm x 0.99mm) | 0.118" L x 0.118" W x 0.039" H (3.00mm x 3.00mm x 0.99mm) | 0.118" L x 0.118" W x 0.039" H (3.00mm x 3.00mm x 0.99mm) | 0.118" L x 0.118" W x 0.039" H (3.00mm x 3.00mm x 0.99mm) |
| Package / Case | 12-VQFN Exposed Pad | 12-VQFN Exposed Pad | 12-VQFN Exposed Pad | 12-VQFN Exposed Pad |
