| Part Number | GALI-24+ | GALI-74+ | GALI-4+ | GALI-29+ | GALI-84+ | GALI-2+ | GALI-21+ |
|---|---|---|---|---|---|---|---|
| Manufacturer | Mini-Circuits | Mini-Circuits | Mini-Circuits | Mini-Circuits | Mini-Circuits | Mini-Circuits | Mini-Circuits |
| Product Status | Active | Active | Active | Active | Active | Active | Active |
| Frequency | 0Hz ~ 6GHz | 0Hz ~ 1GHz | 0Hz ~ 4GHz | 0Hz ~ 7GHz | 0Hz ~ 6GHz | 0Hz ~ 8GHz | 0Hz ~ 8GHz |
| P1dB | 19.4dBm | 19.2dBm | 17.5dBm | 11.2dBm | 21.9dBm | 12.9dBm | 12.6dBm |
| Gain | 12.4dB | 13.4dB | 13.1dB | 12.5dB | 11.8dB | 15.1dB | 9dB |
| Noise Figure | 5.3dB | 2.7dB | 4dB | 6dB | 5.3dB | 4.6dB | 4dB |
| RF Type | CATV, DBS, MMDS, Wireless LAN | Cellular | Cellular, PCS | Cellular, PCS | CATV, DBS, MMDS, Wireless LAN | Cellular, PCS | Cellular, PCS |
| Voltage - Supply | 5.4V ~ 6.2V | 4.3V ~ 5.3V | 4.2V ~ 5.5V | 3.2V ~ 4V | 5.4V ~ 6.2V | 3V ~ 4.1V | 3V ~ 4.1V |
| Current - Supply | 80mA | 80mA | 65mA | 40mA | 100mA | 40mA | 40mA |
| Test Frequency | 2GHz | 100MHz | 1GHz | 7GHz | 100MHz | 2GHz | 2GHz |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | TO-243AA | TO-243AA | TO-243AA | TO-243AA | TO-243AA | TO-243AA | TO-243AA |
| Supplier Device Package | SOT-89 | SOT-89 | SOT-89 | SOT-89 | SOT-89 | SOT-89 | SOT-89 |
