| Part Number | MXP5KE51CA | MXP5KE54CA | MXP5KE58CA | MXP5KE51A |
|---|---|---|---|---|
| Manufacturer | Microsemi Corporation | Microsemi Corporation | Microsemi Corporation | Microsemi Corporation |
| Product Status | Obsolete | Obsolete | Obsolete | Obsolete |
| Type | Zener | Zener | Zener | Zener |
| Unidirectional Channels | - | - | - | 1 |
| Bidirectional Channels | 1 | 1 | 1 | - |
| Voltage - Reverse Standoff (Typ) | 51V | 54V | 58V | 51V |
| Voltage - Breakdown (Min) | 56.7V | 60V | 64.4V | 56.7V |
| Voltage - Clamping (Max) @ Ipp | 82.4V | 87.1V | 93.6V | 82.4V |
| Current - Peak Pulse (10/1000µs) | 6.1A | 5.7A | 5.3A | 6.1A |
| Power - Peak Pulse | 500W | 500W | 500W | 500W |
| Power Line Protection | No | No | No | No |
| Applications | General Purpose | General Purpose | General Purpose | General Purpose |
| Capacitance @ Frequency | - | - | - | - |
| Operating Temperature | -65°C ~ 150°C (TJ) | -65°C ~ 150°C (TJ) | -65°C ~ 150°C (TJ) | -65°C ~ 150°C (TJ) |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole |
| Package / Case | DO-204AL, DO-41, Axial | DO-204AL, DO-41, Axial | DO-204AL, DO-41, Axial | DO-204AL, DO-41, Axial |
| Supplier Device Package | DO-204AL (DO-41) | DO-204AL (DO-41) | DO-204AL (DO-41) | DO-204AL (DO-41) |
