Please send RFQ , we will respond immediately.
| Part Number | MPLAD6.5KP51A | MPLAD6.5KP51CA | MPLAD6.5KP54A | MPLAD6.5KP58A |
|---|---|---|---|---|
| Manufacturer | Microsemi Corporation | Microsemi Corporation | Microsemi Corporation | Microsemi Corporation |
| Product Status | Active | Active | Active | Active |
| Type | Zener | Zener | Zener | Zener |
| Unidirectional Channels | 1 | - | 1 | 1 |
| Bidirectional Channels | - | 1 | - | - |
| Voltage - Reverse Standoff (Typ) | 51V | 51V | 54V | 58V |
| Voltage - Breakdown (Min) | 56.7V | 56.7V | 60V | 64.4V |
| Voltage - Clamping (Max) @ Ipp | 82.4V | 82.4V | 87.1V | 93.6V |
| Current - Peak Pulse (10/1000µs) | 78.8A | 78.8A | 74.8A | 69.1A |
| Power - Peak Pulse | 6500W (6.5kW) | 6500W (6.5kW) | 6500W (6.5kW) | 6500W (6.5kW) |
| Power Line Protection | No | No | No | No |
| Applications | General Purpose | General Purpose | General Purpose | General Purpose |
| Capacitance @ Frequency | - | - | - | - |
| Operating Temperature | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | Nonstandard SMD | Nonstandard SMD | Nonstandard SMD | Nonstandard SMD |
| Supplier Device Package | PLAD | PLAD | PLAD | PLAD |
