| Part Number | APT35SM70S | APT35SM70B |
|---|---|---|
| Manufacturer | Microsemi Corporation | Microsemi Corporation |
| Product Status | Obsolete | Obsolete |
| FET Type | - | N-Channel |
| Technology | SiCFET (Silicon Carbide) | SiCFET (Silicon Carbide) |
| Drain to Source Voltage (Vdss) | 700 V | 700 V |
| Current - Continuous Drain (Id) @ 25°C | 35A | 35A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | - | 20V |
| Rds On (Max) @ Id, Vgs | - | 145mOhm @ 10A, 20V |
| Vgs(th) (Max) @ Id | - | 2.5V @ 1mA |
| Gate Charge (Qg) (Max) @ Vgs | - | 67 nC @ 20 V |
| Vgs (Max) | - | +25V, -10V |
| Input Capacitance (Ciss) (Max) @ Vds | - | 1035 pF @ 700 V |
| FET Feature | - | - |
| Power Dissipation (Max) | - | 176W (Tc) |
| Operating Temperature | - | -55°C ~ 175°C (TJ) |
| Mounting Type | Through Hole | Through Hole |
| Supplier Device Package | TO-247-3 | TO-247-3 |
| Package / Case | TO-247-3 | TO-247-3 |
