| Part Number | APT200GN60JDQ4G | APT200GN60JDQ4 |
|---|---|---|
| Manufacturer | Microsemi Corporation | Microchip Technology |
| Product Status | Discontinued at Digi-Key | Active |
| IGBT Type | Trench Field Stop | Trench Field Stop |
| Configuration | Single | Single |
| Voltage - Collector Emitter Breakdown (Max) | 600 V | 600 V |
| Current - Collector (Ic) (Max) | 283 A | 283 A |
| Power - Max | 682 W | 682 W |
| Vce(on) (Max) @ Vge, Ic | 1.85V @ 15V, 200A | 1.85V @ 15V, 200A |
| Current - Collector Cutoff (Max) | 50 µA | 50 µA |
| Input Capacitance (Cies) @ Vce | 14.1 nF @ 25 V | 14.1 nF @ 25 V |
| Input | Standard | Standard |
| NTC Thermistor | No | No |
| Operating Temperature | -55°C ~ 175°C (TJ) | -55°C ~ 175°C (TJ) |
| Mounting Type | Chassis Mount | Chassis Mount |
| Package / Case | ISOTOP | ISOTOP |
| Supplier Device Package | ISOTOP® | ISOTOP® |
