| Part Number | 1N5227DO35E3 | 1N5229DO35E3 |
|---|---|---|
| Manufacturer | Microsemi Corporation | Microsemi Corporation |
| Product Status | Discontinued at Digi-Key | Discontinued at Digi-Key |
| Voltage - Zener (Nom) (Vz) | 3.6 V | 4.3 V |
| Tolerance | ±5% | ±5% |
| Power - Max | 500 mW | 500 mW |
| Impedance (Max) (Zzt) | 24 Ohms | 22 Ohms |
| Current - Reverse Leakage @ Vr | 15 µA @ 1 V | 5 µA @ 1 V |
| Voltage - Forward (Vf) (Max) @ If | 1.5 V @ 200 mA | 1.5 V @ 200 mA |
| Operating Temperature | -65°C ~ 175°C | -65°C ~ 175°C |
| Mounting Type | Through Hole | Through Hole |
| Package / Case | DO-204AH, DO-35, Axial | DO-204AH, DO-35, Axial |
| Supplier Device Package | DO-35 | DO-35 |
