Please send RFQ , we will respond immediately.
| Part Number | 1N4731 G | 1N4731A G | 1N4733 G | 1N4730 G |
|---|---|---|---|---|
| Manufacturer | Microsemi Corporation | Microsemi Corporation | Microsemi Corporation | Microsemi Corporation |
| Product Status | Active | Active | Active | Active |
| Voltage - Zener (Nom) (Vz) | 4.3 V | 4.3 V | 5.1 V | 3.9 V |
| Tolerance | ±10% | ±5% | ±10% | ±10% |
| Power - Max | 1 W | 1 W | 1 W | 1 W |
| Impedance (Max) (Zzt) | 9 Ohms | 9 Ohms | 7 Ohms | 9 Ohms |
| Current - Reverse Leakage @ Vr | 10 µA @ 1 V | 10 µA @ 1 V | 10 µA @ 1 V | 50 µA @ 1 V |
| Voltage - Forward (Vf) (Max) @ If | 1.2 V @ 200 mA | 1.2 V @ 200 mA | 1.2 V @ 200 mA | 1.2 V @ 200 mA |
| Operating Temperature | -65°C ~ 175°C | -65°C ~ 175°C | -65°C ~ 175°C | -65°C ~ 175°C |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole |
| Package / Case | DO-204AL, DO-41, Axial | DO-204AL, DO-41, Axial | DO-204AL, DO-41, Axial | DO-204AL, DO-41, Axial |
| Supplier Device Package | DO-204AL (DO-41) | DO-204AL (DO-41) | DO-204AL (DO-41) | DO-204AL (DO-41) |
