Microchip Technology-VXB1-1GJ-20-14M3181800 - Crystals Product Specifications and Latest Quotes

Type:	MHz Crystal
Frequency:	14.31818 MHz
Frequency Stability:	±30ppm
Frequency Tolerance:	±20ppm
Load Capacitance:	20pF
ESR (Equivalent Series Resistance):	35 Ohms
Operating Mode:	Fundamental
Operating Temperature:	-20°C ~ 70°C
Ratings:	-
Mounting Type:	Surface Mount
Package / Case:	HC-49/US
Size / Dimension:	0.449" L x 0.191" W (11.40mm x 4.85mm)
Height - Seated (Max):	0.126" (3.20mm)

Microchip Technology VXB1-1GJ-20-14M3181800
