| Part Number | UCS2114-1-V/LX | UCS2114T-1-V/LX |
|---|---|---|
| Manufacturer | Microchip Technology | Microchip Technology |
| Product Status | Active | Active |
| Switch Type | USB Switch | USB Switch |
| Number of Outputs | 2 | 2 |
| Ratio - Input:Output | 1:1 | 1:1 |
| Output Configuration | High Side | High Side |
| Output Type | - | - |
| Interface | I²C, SMBus | I²C, SMBus |
| Voltage - Load | 2.9V ~ 5.5V | 2.9V ~ 5.5V |
| Voltage - Supply (Vcc/Vdd) | 4.5V ~ 5.5V | 4.5V ~ 5.5V |
| Current - Output (Max) | 3A | 3A |
| Rds On (Typ) | 18mOhm | 18mOhm |
| Input Type | - | - |
| Features | - | - |
| Fault Protection | Current Limiting (Fixed), Over Temperature, Over Voltage, UVLO | Current Limiting (Fixed), Over Temperature, Over Voltage, UVLO |
| Operating Temperature | -40°C ~ 105°C (TA) | -40°C ~ 105°C (TA) |
| Mounting Type | Surface Mount | Surface Mount |
| Supplier Device Package | 20-VQFN (3x3) | 20-VQFN (3x3) |
| Package / Case | 20-VFQFN | 20-VFQFN |
