Microchip Technology-MSCSM70AM07CT3AG - Transistors - FETs, MOSFETs - Arrays Product Specifications and Latest Quotes

FET Type:	2 N Channel (Phase Leg)
FET Feature:	Silicon Carbide (SiC)
Drain to Source Voltage (Vdss):	700V
Current - Continuous Drain (Id) @ 25°C:	353A (Tc)
Rds On (Max) @ Id, Vgs:	6.4mOhm @ 120A, 20V
Vgs(th) (Max) @ Id:	2.4V @ 12mA
Gate Charge (Qg) (Max) @ Vgs:	645nC @ 20V
Input Capacitance (Ciss) (Max) @ Vds:	13500pF @ 700V
Power - Max:	988W (Tc)
Operating Temperature:	-40°C ~ 175°C (TJ)
Mounting Type:	Chassis Mount
Package / Case:	Module
Supplier Device Package:	SP3F

Microchip Technology MSCSM70AM07CT3AG
