| Part Number | MIC69301-1.2WR | MIC69301-1.2WU |
|---|---|---|
| Manufacturer | Microchip Technology | Microchip Technology |
| Product Status | Active | Active |
| Output Configuration | Positive | Positive |
| Output Type | Fixed | Fixed |
| Number of Regulators | 1 | 1 |
| Voltage - Input (Max) | 5.5V | 5.5V |
| Voltage - Output (Min/Fixed) | 1.2V | 1.2V |
| Voltage - Output (Max) | - | - |
| Voltage Dropout (Max) | 0.5V @ 3A | 0.5V @ 3A |
| Current - Output | 3A | 3A |
| Current - Quiescent (Iq) | 5 mA | 5 mA |
| Current - Supply (Max) | 75 mA | 75 mA |
| PSRR | - | - |
| Control Features | Enable, Error Flag | Enable, Error Flag |
| Protection Features | Over Current, Over Temperature | Over Current, Over Temperature |
| Operating Temperature | -40°C ~ 125°C | -40°C ~ 125°C |
| Mounting Type | Surface Mount | Surface Mount |
| Package / Case | SPak-5 (5 leads + Tab) | TO-263-6, D²Pak (5 Leads + Tab), TO-263BA |
| Supplier Device Package | S-PAK-5 | TO-263-5 |
