| Part Number | MIC33030-4YHJ-TR | MIC33030-GYHJ-TR | MIC33030-AYHJ-TR | MIC33030-JYHJ-TR |
|---|---|---|---|---|
| Manufacturer | Microchip Technology | Microchip Technology | Microchip Technology | Microchip Technology |
| Product Status | Active | Active | Active | Active |
| Function | Step-Down | Step-Down | Step-Down | Step-Down |
| Output Configuration | Positive | Positive | Positive | Positive |
| Topology | Buck | Buck | Buck | Buck |
| Output Type | Fixed | Fixed | Adjustable | Fixed |
| Number of Outputs | 1 | 1 | 1 | 1 |
| Voltage - Input (Min) | 2.7V | 2.7V | 2.7V | 2.7V |
| Voltage - Input (Max) | 5.5V | 5.5V | 5.5V | 5.5V |
| Voltage - Output (Min/Fixed) | 1.2V | 1.8V | 0.7V | 2.5V |
| Voltage - Output (Max) | - | - | 3.6V | - |
| Current - Output | 400mA | 400mA | 400mA | 400mA |
| Frequency - Switching | 8MHz | 8MHz | 8MHz | 8MHz |
| Synchronous Rectifier | Yes | Yes | Yes | Yes |
| Operating Temperature | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 10-PowerTFDFN, 10-MLF® | 10-PowerTFDFN, 10-MLF® | 10-PowerTFDFN, 10-MLF® | 10-PowerTFDFN, 10-MLF® |
| Supplier Device Package | 10-MLF® (2.5x2) | 10-MLF® (2.5x2) | 10-MLF® (2.5x2) | 10-MLF® (2.5x2) |
