| Part Number | MCP1633T-E/MG | MCP1633-E/MG |
|---|---|---|
| Manufacturer | Microchip Technology | Microchip Technology |
| Product Status | Active | Active |
| Output Type | Transistor Driver | Transistor Driver |
| Function | Step-Up, Step-Up/Step-Down | Step-Up, Step-Up/Step-Down |
| Output Configuration | Positive | Positive |
| Topology | Boost, Cuk, Flyback, SEPIC | Boost, Cuk, Flyback, SEPIC |
| Number of Outputs | 1 | 1 |
| Output Phases | - | - |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 5.5V | 3V ~ 5.5V |
| Frequency - Switching | 200kHz ~ 2.2MHz | 200kHz ~ 2.2MHz |
| Duty Cycle (Max) | 90% | 90% |
| Synchronous Rectifier | No | No |
| Clock Sync | Yes | Yes |
| Serial Interfaces | - | - |
| Control Features | Current Limit, Enable, Frequency Control, Soft Start | Current Limit, Enable, Frequency Control, Soft Start |
| Operating Temperature | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount | Surface Mount |
| Package / Case | 16-VFQFN Exposed Pad | 16-VFQFN Exposed Pad |
| Supplier Device Package | 16-QFN (3x3) | 16-QFN (3x3) |
