| Part Number | M2S090-1FG676I | M2S090-FG676I | M2S090-1FGG676I | M2S090T-1FG676I | M2S090S-1FG676I | M2S090-1FG676 |
|---|---|---|---|---|---|---|
| Manufacturer | Microchip Technology | Microchip Technology | Microchip Technology | Microchip Technology | Microsemi Corporation | Microchip Technology |
| Product Status | Active | Active | Active | Active | Obsolete | Active |
| Architecture | MCU, FPGA | MCU, FPGA | MCU, FPGA | MCU, FPGA | MCU, FPGA | MCU, FPGA |
| Core Processor | ARM® Cortex®-M3 | ARM® Cortex®-M3 | ARM® Cortex®-M3 | ARM® Cortex®-M3 | ARM® Cortex®-M3 | ARM® Cortex®-M3 |
| Flash Size | 512KB | 512KB | 512KB | 512KB | 512KB | 512KB |
| RAM Size | 64KB | 64KB | 64KB | 64KB | 64KB | 64KB |
| Peripherals | DDR, PCIe, SERDES | DDR, PCIe, SERDES | DDR, PCIe, SERDES | DDR, PCIe, SERDES | DDR, PCIe, SERDES | DDR, PCIe, SERDES |
| Connectivity | CANbus, Ethernet, I²C, SPI, UART/USART, USB | CANbus, Ethernet, I²C, SPI, UART/USART, USB | CANbus, Ethernet, I²C, SPI, UART/USART, USB | CANbus, Ethernet, I²C, SPI, UART/USART, USB | CANbus, Ethernet, I²C, SPI, UART/USART, USB | CANbus, Ethernet, I²C, SPI, UART/USART, USB |
| Speed | 166MHz | 166MHz | 166MHz | 166MHz | 166MHz | 166MHz |
| Primary Attributes | FPGA - 90K Logic Modules | FPGA - 90K Logic Modules | FPGA - 90K Logic Modules | FPGA - 90K Logic Modules | FPGA - 90K Logic Modules | FPGA - 90K Logic Modules |
| Operating Temperature | -40°C ~ 100°C (TJ) | -40°C ~ 100°C (TJ) | -40°C ~ 100°C (TJ) | -40°C ~ 100°C (TJ) | -40°C ~ 100°C (TJ) | 0°C ~ 85°C (TJ) |
| Package / Case | 676-BGA | 676-BGA | 676-BGA | 676-BGA | 676-BGA | 676-BGA |
| Supplier Device Package | 676-FBGA (27x27) | 676-FBGA (27x27) | 676-FBGA (27x27) | 676-FBGA (27x27) | 676-FBGA (27x27) | 676-FBGA (27x27) |
