| Part Number | LXP1002-23-4 | LXP1000-23-4 | LXP1002-23-0 | LXP1002-23-2 |
|---|---|---|---|---|
| Manufacturer | Microchip Technology | Microchip Technology | Microchip Technology | Microchip Technology |
| Product Status | Active | Active | Active | Active |
| Diode Type | PIN - 1 Pair Series Connection | PIN - 1 Pair Common Cathode | PIN - Single | PIN - 1 Pair Series Connection |
| Voltage - Peak Reverse (Max) | 50V | 5V | 50V | 50V |
| Current - Max | 100 mA | 1 A | 100 mA | 100 mA |
| Capacitance @ Vr, F | 0.32pF @ 50V, 1MHz | 0.28pF @ 5V, 1MHz | 0.32pF @ 50V, 1MHz | 0.32pF @ 50V, 1MHz |
| Resistance @ If, F | 4Ohm @ 100mA, 100MHz | 2.5Ohm @ 5mA, 100MHz | 4Ohm @ 100mA, 100MHz | 4Ohm @ 100mA, 100MHz |
| Power Dissipation (Max) | 250 mW | 250 mW | 250 mW | 250 mW |
| Operating Temperature | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C |
| Package / Case | TO-236-3, SC-59, SOT-23-3 | TO-236-3, SC-59, SOT-23-3 | TO-236-3, SC-59, SOT-23-3 | TO-236-3, SC-59, SOT-23-3 |
| Supplier Device Package | SOT-23-3 | SOT-23-3 | SOT-23-3 | SOT-23-3 |
