Microchip Technology-JANTXV2N3441 - Transistors - Bipolar (BJT) - Single Product Specifications and Latest Quotes

Part Number	JANTXV2N3441	JANTXV2N3741	JANTXV2N3421	JANTXV2N3440
Manufacturer	Microchip Technology	Microchip Technology	MACOM Technology Solutions	Microchip Technology
Product Status	Active	Active	Discontinued at Digi-Key	Active
Transistor Type	NPN	PNP	NPN	NPN
Current - Collector (Ic) (Max)	3 A	4 A	3 A	1 A
Voltage - Collector Emitter Breakdown (Max)	140 V	80 V	80 V	250 V
Vce Saturation (Max) @ Ib, Ic	1V @ 50mA, 500mA	600mV @ 125mA, 1A	500mV @ 50mA, 500mA	500mV @ 4mA, 50mA
Current - Collector Cutoff (Max)	-	10µA	5µA	2µA
DC Current Gain (hFE) (Min) @ Ic, Vce	25 @ 500mA, 4V	30 @ 250mA, 1V	40 @ 1A, 2V	40 @ 20mA, 10V
Power - Max	3 W	25 W	1 W	800 mW
Frequency - Transition	-	-	-	-
Operating Temperature	-65°C ~ 200°C (TJ)	-65°C ~ 200°C (TJ)	-65°C ~ 200°C (TJ)	-65°C ~ 200°C (TJ)
Mounting Type	Through Hole	Through Hole	Through Hole	Through Hole
Package / Case	TO-213AA, TO-66-2	TO-213AA, TO-66-2	TO-205AA, TO-5-3 Metal Can	TO-205AD, TO-39-3 Metal Can
Supplier Device Package	TO-66 (TO-213AA)	TO-66 (TO-213AA)	TO-5	TO-39

Transistor Type:	NPN
Current - Collector (Ic) (Max):	3 A
Voltage - Collector Emitter Breakdown (Max):	140 V
Vce Saturation (Max) @ Ib, Ic:	1V @ 50mA, 500mA
Current - Collector Cutoff (Max):	-
DC Current Gain (hFE) (Min) @ Ic, Vce:	25 @ 500mA, 4V
Power - Max:	3 W
Frequency - Transition:	-
Operating Temperature:	-65°C ~ 200°C (TJ)
Mounting Type:	Through Hole
Package / Case:	TO-213AA, TO-66-2
Supplier Device Package:	TO-66 (TO-213AA)

Microchip Technology JANTXV2N3441
