Please send RFQ , we will respond immediately.
| Part Number | JANTX1N6132A/TR | JANTX1N6162A/TR | JANTX1N6139A/TR |
|---|---|---|---|
| Manufacturer | Microchip Technology | Microchip Technology | Microchip Technology |
| Product Status | Active | Active | Active |
| Type | Zener | Zener | Zener |
| Unidirectional Channels | - | - | - |
| Bidirectional Channels | 1 | 1 | 1 |
| Voltage - Reverse Standoff (Typ) | 91.2V | 51.7V | 5.7V |
| Voltage - Breakdown (Min) | 114V | 64.6V | 7.13V |
| Voltage - Clamping (Max) @ Ipp | 165.1V | 97.1V | 11.2V |
| Current - Peak Pulse (10/1000µs) | 3A | 15.4A | 133.9A |
| Power - Peak Pulse | 500W | 1500W (1.5kW) | 1500W (1.5kW) |
| Power Line Protection | No | No | No |
| Applications | General Purpose | General Purpose | General Purpose |
| Capacitance @ Frequency | - | - | - |
| Operating Temperature | -55°C ~ 175°C (TJ) | -55°C ~ 175°C (TJ) | -55°C ~ 175°C (TJ) |
| Mounting Type | Through Hole | Through Hole | Through Hole |
| Package / Case | B, Axial | G, Axial | G, Axial |
| Supplier Device Package | Axial | C, Axial | C, Axial |
