| Part Number | JANS1N6640 | JANS1N6642 | JANS1N6641 |
|---|---|---|---|
| Manufacturer | Microchip Technology | Microchip Technology | Microchip Technology |
| Product Status | Active | Active | Active |
| Diode Type | Standard | Standard | Standard |
| Voltage - DC Reverse (Vr) (Max) | 50 V | 75 V | 100 V |
| Current - Average Rectified (Io) | 300mA | 300mA | 300mA |
| Voltage - Forward (Vf) (Max) @ If | 1 V @ 200 mA | 1.2 V @ 100 mA | 1.1 V @ 200 mA |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) | Fast Recovery =< 500ns, > 200mA (Io) | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 4 ns | 5 ns | 5 ns |
| Current - Reverse Leakage @ Vr | 100 nA @ 50 V | 500 nA @ 75 V | 100 nA @ 50 V |
| Capacitance @ Vr, F | - | 5pF @ 0V, 1MHz | - |
| Mounting Type | Through Hole | Through Hole | Through Hole |
| Package / Case | DO-204AH, DO-35, Axial | DO-204AH, DO-35, Axial | DO-204AH, DO-35, Axial |
| Supplier Device Package | - | - | DO-35 (DO-204AH) |
| Operating Temperature - Junction | -65°C ~ 175°C | -65°C ~ 175°C | -65°C ~ 175°C |
