Microchip Technology-JAN2N5672 - Transistors - Bipolar (BJT) - Single Product Specifications and Latest Quotes

Transistor Type:	NPN
Current - Collector (Ic) (Max):	30 A
Voltage - Collector Emitter Breakdown (Max):	120 V
Vce Saturation (Max) @ Ib, Ic:	5V @ 6A, 30A
Current - Collector Cutoff (Max):	10mA
DC Current Gain (hFE) (Min) @ Ic, Vce:	20 @ 20A, 5V
Power - Max:	6 W
Frequency - Transition:	-
Operating Temperature:	-65°C ~ 200°C (TJ)
Mounting Type:	Through Hole
Package / Case:	TO-204AA, TO-3
Supplier Device Package:	TO-3

Microchip Technology JAN2N5672
