| Part Number | DSC6121CE2A-0082T | DSC6121CE2A-0081T | DSC6121CE2A-0082 |
|---|---|---|---|
| Manufacturer | Microchip Technology | Microchip Technology | Microchip Technology |
| Product Status | Obsolete | Obsolete | Obsolete |
| Base Resonator | MEMS | MEMS | MEMS |
| Type | XO (Standard) | XO (Standard) | XO (Standard) |
| Frequency - Output 1 | 45.1584MHz, 49.152MHz | 22.5792MHz, 24.576MHz | 45.1584MHz, 49.152MHz |
| Frequency - Output 2 | - | - | - |
| Frequency - Output 3 | - | - | - |
| Frequency - Output 4 | - | - | - |
| Function | - | - | - |
| Output | CMOS | CMOS | CMOS |
| Voltage - Supply | 1.71V ~ 3.63V | 1.71V ~ 3.63V | 1.71V ~ 3.63V |
| Frequency Stability | ±25ppm | ±25ppm | ±25ppm |
| Operating Temperature | -20°C ~ 70°C | -20°C ~ 70°C | -20°C ~ 70°C |
| Current - Supply (Max) | 3mA (Typ) | 3mA (Typ) | 3mA (Typ) |
| Ratings | - | - | - |
| Size / Dimension | 0.126" L x 0.098" W (3.20mm x 2.50mm) | 0.126" L x 0.098" W (3.20mm x 2.50mm) | 0.126" L x 0.098" W (3.20mm x 2.50mm) |
| Height | 0.035" (0.90mm) | 0.035" (0.90mm) | 0.035" (0.90mm) |
| Package / Case | 4-VDFN | 4-VDFN | 4-VDFN |
