Please send RFQ , we will respond immediately.
| Part Number | CD958B | CD968B | CD978B | CD959B | CD957B |
|---|---|---|---|---|---|
| Manufacturer | Microchip Technology | Microchip Technology | Microchip Technology | Microchip Technology | Microchip Technology |
| Product Status | Active | Active | Active | Active | Active |
| Voltage - Zener (Nom) (Vz) | 7.5 V | 20 V | 51 V | 8.2 V | 6.8 V |
| Tolerance | ±5% | ±5% | ±5% | ±5% | ±5% |
| Power - Max | 500 mW | 500 mW | 500 mW | 500 mW | 500 mW |
| Impedance (Max) (Zzt) | 5.5 Ohms | 25 Ohms | 125 Ohms | 6.5 Ohms | 4.5 Ohms |
| Current - Reverse Leakage @ Vr | 5 µA @ 5.7 V | 500 nA @ 15 V | 500 nA @ 39 V | 5 µA @ 6.2 V | 5 µA @ 5.2 V |
| Voltage - Forward (Vf) (Max) @ If | 1.5 V @ 200 mA | 1.5 V @ 200 mA | 1.5 V @ 200 mA | 1.5 V @ 200 mA | 1.5 V @ 200 mA |
| Operating Temperature | -65°C ~ 175°C | -65°C ~ 175°C | -65°C ~ 175°C | -65°C ~ 175°C | -65°C ~ 175°C |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | Die | Die | Die | Die | Die |
| Supplier Device Package | Die | Die | Die | Die | Die |
