Please send RFQ , we will respond immediately.
| Part Number | BM78SPP05NC2-0002AA | BM78SPPS5NC2-0002AA | BM78SPP05MC2-0002AA | BM78SPP05NC2-0001AA |
|---|---|---|---|---|
| Manufacturer | Microchip Technology | Microchip Technology | Microchip Technology | Microchip Technology |
| Product Status | Active | Active | Active | Active |
| RF Family/Standard | Bluetooth | Bluetooth | Bluetooth | Bluetooth |
| Protocol | Bluetooth v4.2 | Bluetooth v4.2 | Bluetooth v4.2 | Bluetooth v4.0 Dual Mode |
| Modulation | - | - | - | - |
| Frequency | 2.4GHz | 2.4GHz | 2.4GHz | 2.4GHz |
| Data Rate | - | 1.5Gbps | - | 115.2kBaud |
| Power - Output | 1.5dBm | 1.5dBm | 1.5dBm | 2dBm |
| Sensitivity | -92dBm | -92dBm | -92dBm | -90dBm |
| Serial Interfaces | UART | UART | UART | UART |
| Antenna Type | Antenna Not Included | Integrated, Chip | Antenna Not Included | Antenna Not Included |
| Utilized IC / Part | - | - | - | - |
| Memory Size | - | - | - | - |
| Voltage - Supply | 3.3V ~ 4.2V | 3.3V ~ 4.2V | 3.2V ~ 4.2V | 3.2V ~ 4.3V |
| Current - Receiving | 37mA | 37mA | 37mA | 37mA |
| Current - Transmitting | 43mA | 43mA | 43mA | 43mA |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Operating Temperature | -20°C ~ 70°C | -20°C ~ 70°C | -20°C ~ 70°C | -20°C ~ 70°C |
| Package / Case | 30-SMD Module | Module | 30-SMD Module | 30-SMD Module |
