| Part Number | BM78SPP05MC2-0004AA | BM78SPPS5MC2-0004AA | BM78SPP05MC2-0002AA |
|---|---|---|---|
| Manufacturer | Microchip Technology | Microchip Technology | Microchip Technology |
| Product Status | Active | Active | Active |
| RF Family/Standard | Bluetooth | Bluetooth | Bluetooth |
| Protocol | Bluetooth v4.2 | Bluetooth v4.2 | Bluetooth v4.2 |
| Modulation | - | - | - |
| Frequency | 2.4GHz | 2.4GHz | 2.4GHz |
| Data Rate | - | - | - |
| Power - Output | 1.5dBm | 1.5dBm | 1.5dBm |
| Sensitivity | -92dBm | -92dBm | -92dBm |
| Serial Interfaces | I²C, UART | I²C, UART | UART |
| Antenna Type | Antenna Not Included, Castellation | Integrated, Chip | Antenna Not Included |
| Utilized IC / Part | - | - | - |
| Memory Size | - | - | - |
| Voltage - Supply | 3.3V ~ 4.2V | 3.3V ~ 4.2V | 3.2V ~ 4.2V |
| Current - Receiving | 37mA | 37mA | 37mA |
| Current - Transmitting | 43mA | 43mA | 43mA |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Operating Temperature | -20°C ~ 70°C | -20°C ~ 70°C | -20°C ~ 70°C |
| Package / Case | Module | Module | 30-SMD Module |
