| Part Number | 2N5794 | 2N5794U | 2N5796 | 2N5793 |
|---|---|---|---|---|
| Manufacturer | Microchip Technology | TT Electronics/Optek Technology | Central Semiconductor Corp | Central Semiconductor Corp |
| Product Status | Active | Active | Obsolete | Obsolete |
| Transistor Type | 2 NPN (Dual) | 2 NPN (Dual) | 2 PNP (Dual) | - |
| Current - Collector (Ic) (Max) | 600mA | 600mA | 600mA | - |
| Voltage - Collector Emitter Breakdown (Max) | 40V | 40V | 60V | - |
| Vce Saturation (Max) @ Ib, Ic | 900mV @ 30mA, 300mA | 900mV @ 30mA, 300mA | - | - |
| Current - Collector Cutoff (Max) | 10µA (ICBO) | 10µA (ICBO) | - | - |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 100 @ 150mA, 10V | 100 @ 150mA, 10V | 100 @ 150mA, 10V | - |
| Power - Max | 600mW | 600mW | 600mW | - |
| Frequency - Transition | - | - | 200MHz | - |
| Operating Temperature | -65°C ~ 200°C (TJ) | -65°C ~ 200°C (TJ) | - | - |
| Mounting Type | Through Hole | Surface Mount | Through Hole | Through Hole |
| Package / Case | TO-78-6 Metal Can | 6-CLCC | TO-78-6 Metal Can | TO-78-6 Metal Can |
| Supplier Device Package | TO-78-6 | 6-CLCC | TO-78-6 | TO-78-6 |
