| Part Number | 2N4915 | 2N4918 | 2N4919 | 2N4912 |
|---|---|---|---|---|
| Manufacturer | Microchip Technology | Solid State Inc. | Solid State Inc. | NTE Electronics, Inc |
| Product Status | Active | Active | Active | Active |
| Transistor Type | PNP | PNP | PNP | PNP |
| Current - Collector (Ic) (Max) | 5 A | 1 A | 1 A | 4 A |
| Voltage - Collector Emitter Breakdown (Max) | 80 V | 40 V | 60 V | 80 V |
| Vce Saturation (Max) @ Ib, Ic | - | 600mV @ 100mA, 1A | 600mV @ 100mA, 1A | - |
| Current - Collector Cutoff (Max) | - | 500µA | 500µA | - |
| DC Current Gain (hFE) (Min) @ Ic, Vce | - | 40 @ 50mA, 1V | 40 @ 50mA, 1V | - |
| Power - Max | 88 W | 30 W | 30 W | 25 W |
| Frequency - Transition | - | 3MHz | 3MHz | - |
| Operating Temperature | - | 150°C (TJ) | 150°C (TJ) | - |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole |
| Package / Case | TO-204AA, TO-3 | TO-225AA, TO-126-3 | TO-225AA, TO-126-3 | TO-213AA, TO-66-2 |
| Supplier Device Package | TO-3 | TO-126 | TO-126 | TO-66 (TO-213AA) |
