| Part Number | 1N821AUR-1 | 1N823AUR-1 | 1N825AUR-1 | 1N827AUR-1 | 1N829AUR-1 | 1N821UR-1 |
|---|---|---|---|---|---|---|
| Manufacturer | Microchip Technology | Microchip Technology | Microchip Technology | Microchip Technology | Microchip Technology | Microchip Technology |
| Product Status | Active | Active | Active | Active | Active | Discontinued at Digi-Key |
| Voltage - Zener (Nom) (Vz) | 6.2 V | 6.2 V | 6.2 V | 6.2 V | 6.2 V | 6.2 V |
| Tolerance | ±5% | ±5% | ±5% | ±5% | ±5% | ±5% |
| Power - Max | 500 mW | 500 mW | 500 mW | 500 mW | 500 mW | 500 mW |
| Impedance (Max) (Zzt) | 10 Ohms | 10 Ohms | 10 Ohms | 10 Ohms | 10 Ohms | 15 Ohms |
| Current - Reverse Leakage @ Vr | 2 µA @ 3 V | 2 µA @ 3 V | 2 µA @ 3 V | 2 µA @ 3 V | 2 µA @ 3 V | 2 µA @ 3 V |
| Voltage - Forward (Vf) (Max) @ If | - | - | - | - | - | - |
| Operating Temperature | -55°C ~ 175°C | -55°C ~ 175°C | -55°C ~ 175°C | -55°C ~ 175°C | -55°C ~ 175°C | -55°C ~ 175°C |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | DO-213AA (Glass) | DO-213AA (Glass) | DO-213AA (Glass) | DO-213AA (Glass) | DO-213AA (Glass) | DO-213AA (Glass) |
| Supplier Device Package | DO-213AA | DO-213AA | DO-213AA | DO-213AA | DO-213AA | DO-213AA |
