| Part Number | 1N6316US | 1N6310US | 1N6311US |
|---|---|---|---|
| Manufacturer | Microchip Technology | Microchip Technology | Microchip Technology |
| Product Status | Active | Active | Discontinued at Digi-Key |
| Voltage - Zener (Nom) (Vz) | 4.7 V | 2.7 V | 3 V |
| Tolerance | - | ±5% | ±5% |
| Power - Max | 500 mW | 500 mW | 500 mW |
| Impedance (Max) (Zzt) | 1.5 kOhms | 30 Ohms | 29 Ohms |
| Current - Reverse Leakage @ Vr | 5 µA @ 3.5 V | 60 µA @ 1 V | 30 µA @ 1 V |
| Voltage - Forward (Vf) (Max) @ If | 1.4 V @ 1 A | 1.4 V @ 1 A | 1.4 V @ 1 A |
| Operating Temperature | -65°C ~ 175°C | -65°C ~ 175°C | -65°C ~ 175°C |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | SQ-MELF, B | SQ-MELF, B | SQ-MELF, B |
| Supplier Device Package | B, SQ-MELF | B, SQ-MELF | B, SQ-MELF |
