| Part Number | 1N6163A | 1N6169A | 1N6063A |
|---|---|---|---|
| Manufacturer | Microchip Technology | Microchip Technology | Microchip Technology |
| Product Status | Active | Discontinued at Digi-Key | Active |
| Type | Zener | Zener | Zener |
| Unidirectional Channels | - | - | - |
| Bidirectional Channels | 1 | 1 | 1 |
| Voltage - Reverse Standoff (Typ) | 56V | 98.8V | 82V |
| Voltage - Breakdown (Min) | 71.3V | 123.5V | 95V |
| Voltage - Clamping (Max) @ Ipp | 103.1V | 178.8V | 137V |
| Current - Peak Pulse (10/1000µs) | 14.5A | 8.4A | 11A |
| Power - Peak Pulse | 1500W (1.5kW) | 1500W (1.5kW) | 1500W (1.5kW) |
| Power Line Protection | No | No | No |
| Applications | General Purpose | General Purpose | General Purpose |
| Capacitance @ Frequency | - | - | - |
| Operating Temperature | -55°C ~ 175°C (TJ) | -55°C ~ 175°C (TJ) | -55°C ~ 175°C (TJ) |
| Mounting Type | Through Hole | Through Hole | Through Hole |
| Package / Case | B, Axial | B, Axial | DO-13 |
| Supplier Device Package | Axial | Axial | DO-13 |
