| Part Number | 1N6074US/TR | 1N6075US/TR |
|---|---|---|
| Manufacturer | Microchip Technology | Microchip Technology |
| Product Status | Active | Active |
| Diode Type | Standard | Standard |
| Voltage - DC Reverse (Vr) (Max) | 100 V | 150 V |
| Current - Average Rectified (Io) | 3A | 3A |
| Voltage - Forward (Vf) (Max) @ If | 2.04 V @ 9.4 A | 2.04 V @ 9.4 A |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 30 ns | 30 ns |
| Current - Reverse Leakage @ Vr | 1 µA @ 100 V | 1 µA @ 150 V |
| Capacitance @ Vr, F | - | - |
| Mounting Type | Surface Mount | Surface Mount |
| Package / Case | SQ-MELF, A | SQ-MELF, A |
| Supplier Device Package | D-5A | D-5A |
| Operating Temperature - Junction | -65°C ~ 155°C | -65°C ~ 155°C |
