Please send RFQ , we will respond immediately.
| Part Number | SP1001-05VTG | SP1001-05XTG | SP1001-05JTG |
|---|---|---|---|
| Manufacturer | Littelfuse Inc. | Littelfuse Inc. | Littelfuse Inc. |
| Product Status | Last Time Buy | Active | Active |
| Type | Zener | Zener | Zener |
| Unidirectional Channels | 5 | 5 | 5 |
| Bidirectional Channels | - | - | - |
| Voltage - Reverse Standoff (Typ) | 5.5V (Max) | 5.5V (Max) | 5.5V (Max) |
| Voltage - Breakdown (Min) | 7V | 7V | 7V |
| Voltage - Clamping (Max) @ Ipp | 13V | 13V | 13V |
| Current - Peak Pulse (10/1000µs) | 2A (8/20µs) | 2A (8/20µs) | 2A (8/20µs) |
| Power - Peak Pulse | - | - | - |
| Power Line Protection | No | No | No |
| Applications | General Purpose | General Purpose | Automotive |
| Capacitance @ Frequency | - | - | - |
| Operating Temperature | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | SOT-963 | SOT-563, SOT-666 | 6-TSSOP, SC-88, SOT-363 |
| Supplier Device Package | SOT-963 | SOT-563 | SC-70-6 |
