| Part Number | P4KE62C-B | P4KE62CA-B | P4KE68C-B | P4KE62-B | P4KE62A-B |
|---|---|---|---|---|---|
| Manufacturer | Littelfuse Inc. | Littelfuse Inc. | Littelfuse Inc. | Littelfuse Inc. | Littelfuse Inc. |
| Product Status | Obsolete | Active | Obsolete | Obsolete | Active |
| Type | Zener | Zener | Zener | Zener | Zener |
| Unidirectional Channels | - | - | - | 1 | 1 |
| Bidirectional Channels | 1 | 1 | 1 | - | - |
| Voltage - Reverse Standoff (Typ) | 53V | 53V | 58.1V | 53V | 53V |
| Voltage - Breakdown (Min) | 55.8V | 58.9V | 61.2V | 55.8V | 58.9V |
| Voltage - Clamping (Max) @ Ipp | 89.25V | 85V | 96.6V | 89.25V | 85V |
| Current - Peak Pulse (10/1000µs) | 4.8A | 4.8A | 4.5A | 4.8A | 4.8A |
| Power - Peak Pulse | 400W | 400W | 400W | 400W | 400W |
| Power Line Protection | No | No | No | No | No |
| Applications | General Purpose | General Purpose | General Purpose | General Purpose | General Purpose |
| Capacitance @ Frequency | - | - | - | - | - |
| Operating Temperature | -55°C ~ 175°C (TJ) | -55°C ~ 175°C (TJ) | -55°C ~ 175°C (TJ) | -55°C ~ 175°C (TJ) | -55°C ~ 175°C (TJ) |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Package / Case | DO-204AL, DO-41, Axial | DO-204AL, DO-41, Axial | DO-204AL, DO-41, Axial | DO-204AL, DO-41, Axial | DO-204AL, DO-41, Axial |
| Supplier Device Package | DO-204AL (DO-41) | DO-204AL (DO-41) | DO-204AL (DO-41) | DO-204AL (DO-41) | DO-204AL (DO-41) |
