| Part Number | P4KE350CA-B | P4KE350CA-G | P4KE30CA-B | P4KE350A-B | P4KE350C-B |
|---|---|---|---|---|---|
| Manufacturer | Littelfuse Inc. | Comchip Technology | Littelfuse Inc. | Littelfuse Inc. | Littelfuse Inc. |
| Product Status | Active | Active | Active | Active | Obsolete |
| Type | Zener | Zener | Zener | Zener | Zener |
| Unidirectional Channels | - | - | - | 1 | - |
| Bidirectional Channels | 1 | 1 | 1 | - | 1 |
| Voltage - Reverse Standoff (Typ) | 300V | 299.3V | 25.6V | 300V | 300V |
| Voltage - Breakdown (Min) | 332V | 332.5V | 28.5V | 332V | 315V |
| Voltage - Clamping (Max) @ Ipp | 482V | 482V | 41.4V | 482V | 506.1V |
| Current - Peak Pulse (10/1000µs) | 850mA | 830mA | 9.9A | 850mA | 850mA |
| Power - Peak Pulse | 400W | 400W | 400W | 400W | 400W |
| Power Line Protection | No | No | No | No | No |
| Applications | General Purpose | General Purpose | General Purpose | General Purpose | General Purpose |
| Capacitance @ Frequency | - | - | - | - | - |
| Operating Temperature | -55°C ~ 175°C (TJ) | -55°C ~ 150°C (TJ) | -55°C ~ 175°C (TJ) | -55°C ~ 175°C (TJ) | -55°C ~ 175°C (TJ) |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Package / Case | DO-204AL, DO-41, Axial | DO-204AL, DO-41, Axial | DO-204AL, DO-41, Axial | DO-204AL, DO-41, Axial | DO-204AL, DO-41, Axial |
| Supplier Device Package | DO-204AL (DO-41) | DO-41 | DO-204AL (DO-41) | DO-204AL (DO-41) | DO-204AL (DO-41) |
