| Part Number | P4KE250-B | P4KE250A-B | P4KE250C-B | P4KE250-G |
|---|---|---|---|---|
| Manufacturer | Littelfuse Inc. | Littelfuse Inc. | Littelfuse Inc. | Comchip Technology |
| Product Status | Obsolete | Active | Obsolete | Obsolete |
| Type | Zener | Zener | Zener | Zener |
| Unidirectional Channels | 1 | 1 | - | 1 |
| Bidirectional Channels | - | - | 1 | - |
| Voltage - Reverse Standoff (Typ) | 214V | 214V | 214V | 202V |
| Voltage - Breakdown (Min) | 225V | 237V | 225V | 225V |
| Voltage - Clamping (Max) @ Ipp | 361.2V | 344V | 361.2V | 360V |
| Current - Peak Pulse (10/1000µs) | 1.2A | 1.2A | 1.2A | 1.1A |
| Power - Peak Pulse | 400W | 400W | 400W | 400W |
| Power Line Protection | No | No | No | No |
| Applications | General Purpose | General Purpose | General Purpose | General Purpose |
| Capacitance @ Frequency | - | - | - | - |
| Operating Temperature | -55°C ~ 175°C (TJ) | -55°C ~ 175°C (TJ) | -55°C ~ 175°C (TJ) | -65°C ~ 175°C (TJ) |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole |
| Package / Case | DO-204AL, DO-41, Axial | DO-204AL, DO-41, Axial | DO-204AL, DO-41, Axial | DO-204AL, DO-41, Axial |
| Supplier Device Package | DO-204AL (DO-41) | DO-204AL (DO-41) | DO-204AL (DO-41) | DO-41 |
