| Part Number | K1200S1URP | K1300S1URP | K1500S1URP | K1400S1URP | K2200S1URP | K1100S1URP |
|---|---|---|---|---|---|---|
| Manufacturer | Littelfuse Inc. | Littelfuse Inc. | Littelfuse Inc. | Littelfuse Inc. | Littelfuse Inc. | Littelfuse Inc. |
| Product Status | Active | Active | Active | Active | Active | Active |
| Voltage - Breakover | 110 ~ 125V | 120 ~ 138V | 142 ~ 157V | 130 ~ 146V | 210 ~ 230V | 104 ~ 118V |
| Current - Breakover | 10 µA | 10 µA | 10 µA | 10 µA | 10 µA | 10 µA |
| Current - Hold (Ih) (Max) | 80 mA | 80 mA | 80 mA | 80 mA | 80 mA | 80 mA |
| Current - Peak Output | 1 A | 1 A | 1 A | 1 A | 1 A | 1 A |
| Operating Temperature | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) | -40°C ~ 150°C (TJ) | -40°C ~ 125°C (TJ) |
| Package / Case | DO-214AC, SMA | DO-214AC, SMA | DO-214AC, SMA | DO-214AC, SMA | DO-214AC, SMA | DO-214AC, SMA |
| Supplier Device Package | DO-214AC (SMA) | DO-214AC (SMA) | DO-214AC (SMA) | DO-214AC (SMA) | DO-214AC (SMA) | DO-214AC |
