| Part Number | JLLS080.VXP | JLLS090.VXP | JLLS070.VXP |
|---|---|---|---|
| Manufacturer | Littelfuse Inc. | Littelfuse Inc. | Littelfuse Inc. |
| Product Status | Active | Active | Active |
| Mounting Type | Bolt Mount | Bolt Mount | Bolt Mount |
| Fuse Type | Cartridge | Cartridge | Cartridge |
| Current Rating (Amps) | 80A | 90A | 70A |
| Voltage Rating - AC | 600 V | 600 V | 600 V |
| Voltage Rating - DC | 300 V | 300 V | 300 V |
| Response Time | Fast Blow | Fast Blow | Fast Blow |
| Applications | Electrical, Industrial | Electrical, Industrial | Electrical, Industrial |
| Features | - | - | - |
| Class | T | T | T |
| Approval Agency | CE, CSA, UL, UR | CE, CSA, UL, UR | CE, CSA, UL, UR |
| Operating Temperature | - | - | - |
| Breaking Capacity @ Rated Voltage | 200kA AC, 20kA DC | 200kA AC, 20kA DC | 200kA AC, 20kA DC |
| Package / Case | Cylindrical, Blade Terminal (Bolt) | Cylindrical, Blade Terminal (Bolt) | Cylindrical, Blade Terminal (Bolt) |
| Size / Dimension | 0.827" Dia x 2.953" L (21.00mm x 75.00mm) | 0.827" Dia x 2.953" L (21.00mm x 75.00mm) | 0.827" Dia x 2.953" L (21.00mm x 75.00mm) |
