| Part Number | ITV4030L0412NR | ITV4030L0812NR | ITV4030L1412NR | ITV4030L0415NR |
|---|---|---|---|---|
| Manufacturer | Littelfuse Inc. | Littelfuse Inc. | Littelfuse Inc. | Littelfuse Inc. |
| Product Status | Active | Active | Active | Active |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Fuse Type | Board Mount | Board Mount | Board Mount | Board Mount |
| Current Rating (Amps) | 12A | 12A | 12A | 15A |
| Voltage Rating - AC | - | - | - | - |
| Voltage Rating - DC | 36 V | 36 V | 36 V | 36 V |
| Response Time | Fast Blow | Fast Blow | Fast Blow | Fast Blow |
| Applications | Battery Protection | Battery Protection | Battery Protection | Battery Protection |
| Features | 3 ~ 4.5V Triggerable | 4 ~ 9V Triggerable | 10.5 ~ 19.6V Triggerable | 3 ~ 4.5V Triggerable |
| Class | - | - | - | - |
| Approval Agency | cURus, TUV | cURus, TUV | cURus, TUV | cURus, TUV |
| Operating Temperature | -10°C ~ 65°C | -10°C ~ 65°C | -10°C ~ 65°C | -10°C ~ 65°C |
| Breaking Capacity @ Rated Voltage | 50A | 50A | 50A | 50A |
| Package / Case | 1612 (4030 Metric) | 1612 (4030 Metric) | 1612 (4030 Metric) | 1612 (4030 Metric) |
| Size / Dimension | 0.157" L x 0.118" W x 0.035" H (4.00mm x 3.00mm x 0.90mm) | 0.157" L x 0.118" W x 0.035" H (4.00mm x 3.00mm x 0.90mm) | 0.157" L x 0.118" W x 0.035" H (4.00mm x 3.00mm x 0.90mm) | 0.157" L x 0.118" W x 0.035" H (4.00mm x 3.00mm x 0.90mm) |
