| Part Number | FEMTOASMDC010F/15-2 | FEMTOSMDC010F/15-2 |
|---|---|---|
| Manufacturer | Littelfuse Inc. | Littelfuse Inc. |
| Product Status | Active | Active |
| Type | Polymeric | Polymeric |
| Voltage - Max | 15V | 15V |
| Current - Max | 10 A | 40 A |
| Current - Hold (Ih) (Max) | 100 mA | 100 mA |
| Current - Trip (It) | 300 mA | 300 mA |
| Time to Trip | 100 ms | 100 ms |
| Resistance - Initial (Ri) (Min) | 2 Ohms | 2 Ohms |
| Resistance - Post Trip (R1) (Max) | 14 Ohms | 14 Ohms |
| Resistance - 25°C (Typ) | - | - |
| Operating Temperature | - | - |
| Ratings | PS300, PS400 | - |
| Mounting Type | Surface Mount | Surface Mount |
| Package / Case | 0603 (1608 Metric) | 0603 (1608 Metric), Concave |
| Size / Dimension | 0.063" L x 0.032" W (1.60mm x 0.80mm) | 0.063" L x 0.032" W (1.60mm x 0.80mm) |
| Height - Seated (Max) | - | - |
| Thickness (Max) | 0.033" (0.85mm) | 0.033" (0.85mm) |
| Lead Spacing | - | - |
