| Part Number | 0LDC250.X | 0LDC450.X | 0LDC350.X | 0LDC750.X | 0LDC650.X | 0LDC150.X | 0LDC200.X |
|---|---|---|---|---|---|---|---|
| Manufacturer | Littelfuse Inc. | Littelfuse Inc. | Littelfuse Inc. | Littelfuse Inc. | Littelfuse Inc. | Littelfuse Inc. | Littelfuse Inc. |
| Product Status | Active | Active | Active | Active | Active | Active | Active |
| Mounting Type | Bolt Mount | Bolt Mount | Bolt Mount | Bolt Mount | Bolt Mount | Bolt Mount | Bolt Mount |
| Fuse Type | Cartridge | Cartridge | Cartridge | Cartridge | Cartridge | Cartridge | Cartridge |
| Current Rating (Amps) | 250A | 450A | 350A | 750A | 650A | 150A | 200A |
| Voltage Rating - AC | 600 V | 600 V | 600 V | 600 V | 600 V | 600 V | 600 V |
| Voltage Rating - DC | 600 V | 600 V | 600 V | 600 V | 600 V | 600 V | 600 V |
| Response Time | Fast Blow | Fast Blow | Fast Blow | Fast Blow | Fast Blow | Fast Blow | Fast Blow |
| Applications | Solar (Photovoltaic) | Solar (Photovoltaic) | Solar (Photovoltaic) | Solar (Photovoltaic) | Solar (Photovoltaic) | Solar (Photovoltaic) | Solar (Photovoltaic) |
| Features | - | - | - | - | - | - | - |
| Class | L | L | L | L | L | L | L |
| Approval Agency | CE, CSA, UR | CE, CSA, UR | CE, CSA, UR | CE, CSA, UL | CE, CSA, UL | CE, CSA, UL | CE, CSA, UR |
| Operating Temperature | - | - | - | - | - | - | - |
| Breaking Capacity @ Rated Voltage | 200kA AC, 50kA DC | 200kA AC, 50kA DC | 200kA AC, 50kA DC | 200kA AC, 50kA DC | 200kA AC, 50kA DC | 200kA AC, 50kA DC | 200kA AC, 50kA DC |
| Package / Case | Cylindrical, Blade Terminal (Bolt) | Cylindrical, Blade Terminal (Bolt) | Cylindrical, Blade Terminal (Bolt) | Cylindrical, Blade Terminal (Bolt) | Cylindrical, Blade Terminal (Bolt) | Cylindrical, Blade Terminal (Bolt) | Cylindrical, Blade Terminal (Bolt) |
| Size / Dimension | 2.500" Dia x 3.752" L (63.50mm x 95.30mm) | 2.500" Dia x 3.752" L (63.50mm x 95.30mm) | 2.500" Dia x 3.752" L (63.50mm x 95.30mm) | 2.500" Dia x 3.752" L (63.50mm x 95.30mm) | 2.500" Dia x 3.752" L (63.50mm x 95.30mm) | 2.500" Dia x 3.752" L (63.50mm x 95.30mm) | 2.500" Dia x 3.752" L (63.50mm x 95.30mm) |
