| Part Number | 0305.200H | 0305.500H | 0305.200M | 0305.250H | 0305.200T | 0305.100H |
|---|---|---|---|---|---|---|
| Manufacturer | Littelfuse Inc. | Littelfuse Inc. | Littelfuse Inc. | Littelfuse Inc. | Littelfuse Inc. | Littelfuse Inc. |
| Product Status | Active | Active | Active | Active | Obsolete | Active |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Fuse Type | Board Mount | Board Mount | Board Mount | Board Mount | Board Mount | Board Mount |
| Current Rating (Amps) | 200mA | 500mA | 200mA | 250mA | 200mA | 100mA |
| Voltage Rating - AC | 277 V | 277 V | 277 V | 277 V | 277 V | 277 V |
| Voltage Rating - DC | 277 V | 277 V | 277 V | 277 V | 277 V | 277 V |
| Response Time | - | - | - | - | - | - |
| Applications | Hazardous Locations | Hazardous Locations | Hazardous Locations | Hazardous Locations | Hazardous Locations | Hazardous Locations |
| Features | Intrinsically Safe | Intrinsically Safe | Intrinsically Safe | Intrinsically Safe | Intrinsically Safe | Intrinsically Safe |
| Class | - | - | - | - | - | - |
| Approval Agency | ATEX, cURus, IECEx | ATEX, cURus, IECEx | ATEX, cURus, IECEx | ATEX, cURus, IECEx | ATEX, cURus, IECEx | ATEX, cURus, IECEx |
| Operating Temperature | -40°C ~ 50°C | -40°C ~ 74°C | -40°C ~ 50°C | -40°C ~ 46°C | -40°C ~ 50°C | -40°C ~ 50°C |
| Breaking Capacity @ Rated Voltage | 1.5kA | 1.5kA | 1.5kA | 1.5kA | 1.5kA | 1.5kA |
| Package / Case | Radial, Can, Horizontal | Radial, Can, Horizontal | Radial, Can, Horizontal | Radial, Can, Horizontal | Radial, Can, Horizontal | Radial, Can, Horizontal |
| Size / Dimension | 0.354" Dia x 0.614" L (9.00mm x 15.60mm) | 0.354" Dia x 0.614" L (9.00mm x 15.60mm) | 0.354" Dia x 0.614" L (9.00mm x 15.60mm) | 0.354" Dia x 0.614" L (9.00mm x 15.60mm) | 0.354" Dia x 0.614" L (9.00mm x 15.60mm) | 0.354" Dia x 0.614" L (9.00mm x 15.60mm) |
