0157.750DR
  • Share:

Littelfuse Inc. 0157.750DR

Manufacturer No:
0157.750DR
Manufacturer:
Littelfuse Inc.
Package:
Tape & Reel (TR)
Datasheet:
0157.750DR Datasheet
ECAD Model:
-
Description:
FUSE BOARD MNT 750MA 125VAC/VDC
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Mounting Type:Holder, Surface Mount
Fuse Type:Board Mount (Cartridge Style Excluded)
Current Rating (Amps):750 mA
Voltage Rating - AC:125 V
Voltage Rating - DC:125 V
Response Time:Fast Blow
Package / Case:2-SMD, Square End Block with Clip
Breaking Capacity @ Rated Voltage:50A
Melting I²t:0.185
Approval Agency:cULus
Operating Temperature:-55°C ~ 125°C
Color:-
Size / Dimension:0.256" L x 0.146" W x 0.154" H (6.50mm x 3.70mm x 3.90mm)
0 Remaining View Similar

In Stock

$2.88
176

Please send RFQ , we will respond immediately.
