| Part Number | LTST-S321GKT | LTST-S321KGKT | LTST-S320GKT | LTST-S321CKT | LTST-S321EKT | LTST-S321FKT |
|---|---|---|---|---|---|---|
| Manufacturer | Lite-On Inc. | Lite-On Inc. | Lite-On Inc. | Lite-On Inc. | Lite-On Inc. | Lite-On Inc. |
| Product Status | Active | Active | Obsolete | Active | Active | Obsolete |
| Color | Green | Green | Green | - | Orange-Red | - |
| Configuration | Standard | Standard | Standard | - | Standard | - |
| Lens Color | Colorless | Colorless | Colorless | - | Colorless | - |
| Lens Transparency | Clear | Clear | Clear | - | Clear | - |
| Millicandela Rating | 12mcd | 35mcd | 10mcd | - | - | - |
| Lens Style | Rectangle with Domed Top | Rectangle with Domed Top | Rectangle with Domed Top | - | Rectangle with Domed Top | - |
| Lens Size | 2.00mm x 1.00mm | 2.00mm x 1.00mm | 2.00mm x 1.00mm | - | 2.00mm x 1.00mm | - |
| Voltage - Forward (Vf) (Typ) | 2.1V | 2V | 2.1V | - | 2V | - |
| Current - Test | 20mA | 20mA | 20mA | - | 20mA | - |
| Viewing Angle | 130° | 130° | 130° | - | 130° | - |
| Mounting Type | Surface Mount, Right Angle | Surface Mount, Right Angle | Surface Mount, Right Angle | Surface Mount, Right Angle | Surface Mount, Right Angle | Surface Mount, Right Angle |
| Wavelength - Dominant | 569nm | 571nm | 569nm | - | 621nm | - |
| Wavelength - Peak | 565nm | 574nm | 565nm | - | 630nm | - |
| Features | - | - | - | - | - | - |
| Package / Case | 2-SMD, No Lead | 2-SMD, No Lead | 2-SMD, No Lead | 2-SMD, No Lead | 2-SMD, No Lead | 2-SMD, No Lead |
| Supplier Device Package | 1208 | 1208 | - | 1208 | 1208 | 1208 |
| Size / Dimension | 3.00mm L x 2.00mm W | 3.00mm L x 2.00mm W | 3.00mm L x 2.00mm W | 3.00mm L x 2.00mm W | 3.00mm L x 2.00mm W | 3.00mm L x 2.00mm W |
| Height (Max) | 1.00mm | 1.00mm | 1.00mm | 1.00mm | 1.00mm | 1.00mm |
