| Part Number | LTST-C170JAKT | LTST-C170KAKT | LTST-C170JRKT | LTST-C170AKT |
|---|---|---|---|---|
| Manufacturer | Lite-On Inc. | Lite-On Inc. | Lite-On Inc. | Lite-On Inc. |
| Product Status | Obsolete | Active | Obsolete | Active |
| Color | Orange-Red | Red-Orange | Red | Orange |
| Configuration | - | Standard | - | Standard |
| Lens Color | - | Colorless | - | Colorless |
| Lens Transparency | - | Clear | - | Clear |
| Millicandela Rating | 30mcd | 54mcd | 30mcd | 2mcd |
| Lens Style | Rectangle | Rectangle with Flat Top | Rectangle | Rectangle with Flat Top |
| Lens Size | 1.40mm x 1.25mm | 1.40mm x 1.25mm | 1.40mm x 1.25mm | 1.40mm x 1.25mm |
| Voltage - Forward (Vf) (Typ) | 2V | 2V | 2V | 2.1V |
| Current - Test | 20mA | 20mA | 20mA | 10mA |
| Viewing Angle | 130° | 130° | 130° | 130° |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Wavelength - Dominant | 621nm | 615nm | 631nm | 602nm |
| Wavelength - Peak | 621nm | 621nm | 639nm | 610nm |
| Features | - | - | - | - |
| Package / Case | 0805 (2012 Metric) | 0805 (2012 Metric) | 0805 (2012 Metric) | 0805 (2012 Metric) |
| Supplier Device Package | - | - | - | - |
| Size / Dimension | 2.00mm L x 1.25mm W | 2.00mm L x 1.25mm W | 2.00mm L x 1.25mm W | 2.00mm L x 1.25mm W |
| Height (Max) | 1.10mm | 1.10mm | 1.10mm | 1.10mm |
