| Part Number | T556B227K008AT | T556B227M008AT | T556B227K008AH |
|---|---|---|---|
| Manufacturer | KEMET | KEMET | KEMET |
| Product Status | Active | Active | Active |
| Capacitance | 220 µF | 220 µF | 220 µF |
| Tolerance | ±10% | ±20% | ±10% |
| Voltage - Rated | 8 V | 8 V | 8 V |
| Type | Hermetically Sealed | Hermetically Sealed | Hermetically Sealed |
| ESR (Equivalent Series Resistance) | 120mOhm @ 100kHz | 120mOhm @ 100kHz | 120mOhm @ 100kHz |
| Operating Temperature | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C |
| Lifetime @ Temp. | 2000 Hrs @ 105°C | 2000 Hrs @ 105°C | 2000 Hrs @ 105°C |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | Nonstandard | Nonstandard | Nonstandard |
| Size / Dimension | 0.965" L x 0.335" W (24.50mm x 8.50mm) | 0.965" L x 0.335" W (24.50mm x 8.50mm) | 0.965" L x 0.335" W (24.50mm x 8.50mm) |
| Height - Seated (Max) | 0.378" (9.60mm) | 0.378" (9.60mm) | 0.378" (9.60mm) |
| Lead Spacing | - | - | - |
| Manufacturer Size Code | B | B | B |
| Ratings | - | - | - |
| Features | General Purpose | General Purpose | General Purpose |
