| Part Number | T551B397K015AT4251 | T551B397M015AT4251 | T551B397K015AH4251 |
|---|---|---|---|
| Manufacturer | KEMET | KEMET | KEMET |
| Product Status | Active | Active | Active |
| Capacitance | 390 µF | 390 µF | 390 µF |
| Tolerance | ±10% | ±20% | ±10% |
| Voltage - Rated | 15 V | 15 V | 15 V |
| Type | Hermetically Sealed | Hermetically Sealed | Hermetically Sealed |
| ESR (Equivalent Series Resistance) | 90mOhm @ 100kHz | 90mOhm @ 100kHz | 90mOhm @ 100kHz |
| Operating Temperature | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C |
| Lifetime @ Temp. | 2000 Hrs @ 85°C | 2000 Hrs @ 85°C | 2000 Hrs @ 85°C |
| Mounting Type | Through Hole | Through Hole | Through Hole |
| Package / Case | Axial, Can | Axial, Can | Axial, Can |
| Size / Dimension | 0.312" Dia x 0.641" L (7.92mm x 16.28mm) | 0.312" Dia x 0.641" L (7.92mm x 16.28mm) | 0.312" Dia x 0.641" L (7.92mm x 16.28mm) |
| Height - Seated (Max) | - | - | - |
| Lead Spacing | - | - | - |
| Manufacturer Size Code | B | B | B |
| Ratings | - | - | - |
| Features | General Purpose | General Purpose | General Purpose |
